HIMA X-CPU01 (985210211) HIMatrix Safety Processor Module

Description

HIMA X-CPU01 (985210211) HIMatrix Safety Processor Module

Product Description

The X-CPU01 with part code 985210211 is the core safety CPU processor module for HIMA HIMatrix safety-related control system. This fail-safe central processing unit executes safety logic programs, handles real-time I/O data acquisition, manages system redundancy, and processes internal diagnostics. It supports distributed safety control and multiple user application programs, with built-in event logging for fault and alarm records. Designed for SIL3 safety-critical applications, it delivers reliable fail-safe response once abnormal conditions are detected. The compact rack-mount module communicates with local I/O modules and upper-level host systems via multiple industrial interfaces, widely adopted for machinery safety, burner management, and process safety shutdown systems.

X-CPU01

Technical Specifications

• Part Number: X-CPU01, 985210211
• Manufacturer: HIMA
• Series: HIMatrix
• Device Type: Fail-safe Safety CPU Processor
• Safety Integrity Level: SIL3 (IEC 61508)
• Power Supply: 24 VDC
• Operating Temperature: -25°C ~ +60°C
• Storage Temperature: -40°C ~ +85°C
• Communication: Ethernet, Modbus TCP, CANopen
• Programming Environment: HIMA Safety programming tool
• Event Memory: Built-in memory for fault & event history storage
• Mounting: DIN rail / rack mount for HIMatrix chassis
• Certification: CE, ATEX, IECEx, UL
• Power Consumption: Approx. 10 W

Key Features

1. SIL3 certified fail-safe processor for safety instrumented systems (SIS)
2. Executes safety application logic, I/O data processing and redundancy management
3. Comprehensive self-diagnosis for hardware and communication faults
4. Onboard event log to record alarms, trips and system operation history
5. Supports multiple communication protocols for connection to PLC, DCS and SCADA
6. Hot swap compatible within HIMatrix rack for simplified maintenance
7. Compact modular design for flexible cabinet layout
8. Fail-safe response mechanism to trigger safety actions during component failure

Application Scenarios

• Oil & gas emergency shutdown systems (ESD)
• Petrochemical plant safety instrumented systems
• Power plant boiler and turbine safety protection
• Burner management systems (BMS)
• Offshore platform machinery safety control
• Pipeline pressure safety monitoring and trip control
• Metallurgy heavy machinery safety interlock
• Chemical reactor overpressure and over-temperature protection

Matching / Auxiliary Components

• HIMatrix system rack and backplane
• HIMA digital input modules (X-AI, X-DI series)
• HIMA digital output modules (X-DO series)
• HIMatrix power supply module X-POWER01
• CAN bus / Ethernet communication cables
• HIMA safety programming software
• HIMatrix termination terminal blocks
• Redundant communication switch for safety network

Related HIMA HIMatrix Series Models (9 pcs)

1. X-DI01 Digital Input Module
2. X-DO01 Digital Output Module
3. X-AI01 Analog Input Module
4. X-AO01 Analog Output Module
5. X-POWER01 Power Supply Module
6. X-COM01 Communication Module
7. X-CPU02 Safety Processor Module
8. X-DI02 High Density DI Module
9. X-DO02 High Density DO Module
