ABB PM825 3BSE010796R1 S800 Processor Module

Description

ABB PM825 3BSE010796R1 S800 Processor Module

Executive Brief

The ABB PM825 3BSE010796R1 is a high-performance core processor module belonging to the ABB S800 I/O system and AC 800M controller series, specially designed for industrial automation and process control scenarios. Built on PowerPC real-time architecture, it delivers robust processing performance and rich communication expansion capabilities, and is widely deployed in industries including electric power, petrochemical and water treatment. The brand new original unit has a standard list price of US3860,withmemberdiscountedpricesstartingfromUS3860,withmemberdiscountedpricesstartingfromUS2994.60, and all units come with a 12-month official warranty.

PM825 3BSE010796R1

Core Technical Specifications

1. Manufacturer: ABB
2. Exact Part Number: PM825, Product ID: 3BSE010796R1
3. Product Category: S800 Processor Module, part of AC 800M controller series
4. Processor Architecture: PowerPC high-performance real-time control architecture
5. Main Frequency: Typical value 400MHz~1GHz
6. Memory Configuration: 64MB~256MB RAM for real-time running, expandable Flash memory for firmware storage
7. Communication Interfaces: S800 I/O bus supporting local/remote I/O expansion; dual-port 10/100Mbps redundant Ethernet; RS-232/485 serial port for debugging or legacy device connection
8. I/O Capabilities: 16 configurable digital input channels, 16 configurable digital output channels
9. Power Supply: 24 VDC standard industrial power input
10. Country of Origin: Sweden
11. Customs Tariff Number: 8538908180
12. Net Weight: 0.280 KG
13. Industrial Protocol Support: Natively supports Modbus RTU/TCP, Profibus, Profinet (via optional expansion modules)
14. Ordering Specification: Minimum order quantity 1 EA, sold in single unit measurement

Key Features & Advantages

• High-performance Real-time Processing: The PowerPC architecture with 400MHz~1GHz main frequency ensures stable and low-latency execution of complex industrial control logic, meeting the strict real-time requirements of process control.
• Rich Redundant Communication Design: Dual-port 10/100Mbps redundant Ethernet eliminates communication single point of failure, effectively improving system operation reliability.
• Flexible I/O Expansion: The dedicated S800 I/O bus supports both local and remote distributed I/O expansion, which can adapt to different scale automation system layout requirements.
• Good Legacy Device Compatibility: The reserved RS-232/485 serial port can be directly connected to old industrial equipment without extra protocol conversion modules, reducing system transformation cost.
• Compact Lightweight Design: The net weight is only 0.28KG, which saves cabinet installation space and is convenient for on-site installation and maintenance.
• Strict Industrial Quality Control: Made in Sweden with ABB’s global industrial manufacturing standards, it has excellent long-term operation stability in harsh industrial environments.

Typical Application Scenarios

1. Electric Power Industry Automation: Core control unit for small and medium-sized power plants, substation auxiliary control systems and distributed power generation stations.
2. Petrochemical Process Control: Main processor for small refining units, chemical production workshops and oil & gas field auxiliary control systems.
3. Water Treatment Projects: Central control for urban water supply plants, sewage treatment facilities and industrial circulating water systems.
4. Light Manufacturing Automation: Core controller for packaging, textile, food processing and other discrete manufacturing production lines.
5. Building & Public Utilities: Automation control for large commercial buildings, logistics warehouses and municipal public facility systems.

Same Series Model Display

1. ABB PM821: Entry-level S800 processor module, designed for small automation projects with moderate performance requirements, offering cost-effective control solutions.
2. ABB PM822: Mid-range processor module, balancing performance and cost for standard industrial control scenarios with medium I/O capacity.
3. ABB PM826: Upgraded processor module, with expanded memory and higher main frequency for medium-large complex control systems.
4. ABB PM827: Flagship processor module, with maximum processing power and largest I/O expansion capacity for large-scale distributed control systems.

Related Supporting Product Model Display

1. ABB DI810: Digital input module, expanding field digital signal acquisition capacity for PM825 control systems.
2. ABB DO810: Digital output module, driving on-site digital actuators under the control of PM825.
3. ABB AI810: Analog input module, collecting analog physical quantity signals such as temperature and pressure for PM825.
4. ABB AO810: Analog output module, outputting 4-20mA analog control signals to drive on-site regulating valves.
5. ABB SS822: Redundant power supply module, providing stable redundant 24V DC power input for to eliminate power supply single point of failure.

Frequently Asked Questions

Q1: What series does 3BSE010796R1 belong to?
A1: It is the core processor module of ABB I/O system, belonging to the AC 800M controller series.

Q2: What is the weight of this processor module?
A2: The net weight of the unit is 0.280 KG, which is very lightweight and easy for on-site installation and maintenance.

Q3: Does support redundant Ethernet communication?
A3: Yes, it is equipped with dual-port 10/100Mbps Ethernet with redundancy support, which can effectively improve communication reliability.

Q4: What is the standard power supply requirement for this module?
A4: It adopts 24 VDC standard industrial power input, which is fully compatible with the power supply specifications of most industrial control systems.

Q5: Where is the country of origin of ?
A5: This product is originally manufactured in Sweden, with strict industrial quality control standards.
