Honeywell CC-TCNT01 C300 Controller Input Output Termination Assembly (IOTA) Module

Description

Honeywell CC-TCNT01 C300 Controller Input Output Termination Assembly (IOTA) Module

Detailed Product Information

The Honeywell CC-TCNT01 is a purpose-built Input Output Termination Assembly (IOTA) designed exclusively for Honeywell C300 distributed control system controllers. It acts as the critical physical interface between the C300 controller’s I/O processing backplane and all field-side industrial signals, enabling seamless, reliable signal routing for both digital and analog process points. The module features a compact, lightweight form factor with a robust industrial housing, built to withstand harsh industrial environments with IP65/IP66 ingress protection ratings. It supports native hot-swap functionality, allowing technicians to perform maintenance and replacement during live system operation without interrupting the normal running of adjacent control loops. The module is factory-certified to UL, CE and ISO 9001 quality standards, and comes with a 12-month official manufacturer warranty to ensure long-term stable performance in demanding process automation scenarios.

CC-TCNT01

Technical Specifications

• Manufacturer: Honeywell
• Part Number: CC-TCNT01
• Product Type: C300 Controller Input Output Termination Assembly (IOTA)
• Operating Voltage: DC 24V
• IOTA Supply Rating: 0.311A @ 24VDC
• Input Current: Max. 10mA per channel
• Output Current: Max. 10mA per channel
• Output Frequency: Up to 60kHz for high-speed pulse signal processing
• Communication Protocol: Modbus RTU for system-level data exchange
• Weight: ≤ 0.22kg
• Operating Temperature Range: -20°C to +60°C
• Storage Temperature Range: -40°C to +85°C
• Environment Compatibility: IP65/IP66 rated for harsh industrial environments
• Certifications: UL, CE, ISO 9001
• Condition: Brand new original factory sealed unit
• Warranty: 12 months
• Origin: USA

Compatibility & Installation Pitfalls

Compatibility

1. Natively interoperable with Honeywell C300 distributed control system controllers and matched I/O backplane architectures
2. Fully compatible with all standard 24V DC industrial field devices including limit switches, proximity sensors, relay contacts and analog transmitters
3. Seamlessly integrates with Honeywell Experion PKS DCS engineering software for full signal mapping, configuration and diagnostic operations
4. Supports standard Modbus RTU protocol for third-party PLC and SCADA system data exchange
5. Matches with industry standard 2.5 mm² shielded field wiring without signal attenuation or false triggering

Installation Pitfalls

1. Never install the CC-TCNT01 in a termination slot designated for other C300 IOTA module types. Mismatched slot configuration will break the signal routing path and cause total I/O communication failure between the controller and field devices.
2. Do not connect field signals with voltage levels exceeding 30V directly to the module’s termination terminals. Overvoltage transients will damage the internal signal conditioning circuits and lead to permanent module failure.
3. Avoid routing field signal cables connected to CC-TCNT01 in the same cable tray as high-power variable frequency drive or AC motor power cables. Uncontrolled electromagnetic interference will cause random signal errors and false process readings.
4. Never perform hot-swap replacement while critical safety interlock loops connected to this module are in active operation without pre-engaging the configured maintenance bypass. This action may cause momentary signal loss and trigger unplanned safety trips.
5. Do not mix CC-TCNT01 modules with drastically different hardware revisions in the same controller cabinet. Inconsistent hardware versions will cause asynchronous signal timing and unexpected process logic conflicts.

CC-TCNT01

Standard Operating Procedure

1. Pre-installation verification: Inspect the CC- module for physical damage on terminals and circuit boards, confirm the controller backplane 24V DC power output is stable within the acceptable operating range.
2. Mechanical mounting: Align the module with the controller cabinet guide rails, slide it smoothly into the designated IOTA slot, and secure the front panel mounting screws to ensure full and reliable electrical contact with the backplane.
3. Field wiring termination: Connect all field devices to their corresponding signal terminals on the CC-, torque every connection to the manufacturer specified value, and apply clear permanent labels for each terminal with its corresponding process tag number.
4. Power-on configuration: Access the Honeywell Experion PKS engineering workstation, complete the IOTA device registration, map each field signal to the corresponding controller I/O channel, and configure signal type, range and related process parameters.
5. Functional validation: Simulate signal status for every connected field device one by one, confirm the corresponding signal status updates correctly on the HMI, verify all channel fault diagnostic alarms trigger as expected under simulated open circuit and short circuit conditions.
6. Commissioning handover: Export and save the final signal mapping configuration profile to secure backup, complete the installation and loop check log, and confirm all connected I/O points are operating normally before releasing the system to full operational service.

Typical Application Scenarios

• Petrochemical refining operations: Serves as the physical signal termination hub for controllers, routing all discrete and analog process signals for distillation units, reactors and heat exchangers.
• Oil and gas production facilities: Deploys in onshore and offshore control cabinets, leveraging its wide operating temperature range and IP65/IP66 ingress protection to adapt to harsh high-dust, high-humidity field environments.
• Power generation and utilities: Acts as the field signal termination interface for controllers in thermal power plants, supporting reliable signal routing for boiler, turbine and auxiliary equipment monitoring and control loops.
• Chemical processing plants: Provides stable signal termination for continuous production process control loops, supporting 24/7 non-stop operation to maximize production uptime.
• Industrial manufacturing facilities: Integrates with Honeywell control systems to deliver reliable signal routing for production line automation, material handling and equipment safety interlock systems.

Recommended Supporting Components

• Honeywell Controller dedicated control cabinet with matched backplane and redundant power supply unit
• Honeywell certified 24V DC industrial field sensors, limit switches, relay contacts and process transmitters
• Shielded Modbus RTU communication cables for interference-free system-level data transmission
• Honeywell official Experion PKS DCS engineering configuration software and diagnostic toolkit
• Flame-retardant 2.5 mm² industrial field wiring terminals with certified strain relief

Related Part Number Recommendations

• CC-TAOX01: Controller Analog Output Termination Assembly, for complementary 4-20mA analog output signal routing
• CC-TAIH01: Controller Analog Input Termination Assembly, dedicated for analog input signal termination and conditioning
• CC-TDIL01: Controller Digital Input Termination Assembly, for discrete digital input signal routing
• CC-TDOL01: Controller Digital Output Termination Assembly, for discrete digital output signal routing
• 51304485-150: Honeywell MC-PDIX02 16-channel digital input module, for discrete status signal acquisition from field devices
