ABB PM861K01 3BSE018105R1 AC 800M Processor Unit Kit

Description

ABB PM861K01 3BSE018105R1 AC 800M Processor Unit Kit

Executive Brief

The ABB PM861K01 3BSE018105R1 is a high-performance core processor module belonging to the ABB AC 800M controller family, designed for System 800xA distributed control systems. Built on 32-bit RISC PowerPC architecture, it supports redundant hot-standby configuration, delivers stable real-time control performance, and is widely deployed in demanding industrial automation, process control and energy management scenarios. All brand new original units come with a 12-month official warranty, and global stock is available for expedited shipping.

ABB PM861K01 3BSE018105R1

Core Technical Specifications

1. Manufacturer: ABB
2. Exact Part Number: PM861K01, Product ID: 3BSE018105R1
3. Product Category: AC 800M Processor Module / CPU
4. Processor Architecture: 32-bit RISC (PowerPC based)
5. Memory Configuration: 8 MB User Memory, 16 MB Flash Storage
6. Communication Ports: 2x RJ45 Ethernet (10/100 Mbps), 1x RS-232 Service Port
7. Bus Interface: CEX-Bus (for I/O and Communication extensions)
8. Redundancy Support: Yes (High Availability / Hot Standby)
9. Status Indicators: RUN, ERR, COMM, RDY LEDs on front panel
10. Power Consumption: Approx. 3.5 W (typical at 5V DC from backplane)
11. Operating Temperature: -20 °C to +70 °C (-4 °F to +158 °F)
12. Storage Temperature: -40 °C to +85 °C (-40 °F to +185 °F)
13. Physical Dimensions: Net Depth/Length 20.3 cm, Net Height 15.7 cm, Net Width 13.5 cm
14. Net Weight: 1.14 kg
15. Country of Origin: Sweden
16. Environmental Classification: Class 9 Miscellaneous Dangerous Goods, UN Number UN3091-PI969; not within WEEE scope

Key Features & Advantages

• High-performance Real-time Processing: 32-bit RISC PowerPC architecture ensures stable low-latency execution of industrial control logic, meeting the strict real-time requirements of process control scenarios.
• Built-in Redundancy Support: Native high availability hot-standby configuration capability effectively eliminates single point of failure, greatly improving system uptime and operation reliability.
• Rich Communication Interfaces: Dual 10/100 Mbps Ethernet ports and RS-232 service port support seamless connection with I/O modules, field devices and upper monitoring platforms.
• Ultra-wide Operating Temperature Range: -20 °C to +70 °C operating temperature range enables stable operation in various harsh industrial site environments.
• Low Power Consumption Design: Typical 3.5 W power dissipation reduces system heat generation and power load, improving long-term operation stability in enclosed industrial cabinets.
• Compact Integrated Design: The complete processor unit kit integrates all core functions, with standardized dimensions that are easy to install and maintain in standard industrial control cabinets.

Typical Application Scenarios

1. Petrochemical Process Control: Core processor for small and medium-sized refineries, chemical plants and oil & gas production auxiliary control systems.
2. Power Generation Automation: Main control unit for small thermal power plants, distributed power generation stations and substation auxiliary control systems.
3. Water Treatment Projects: Central control for urban water supply plants, sewage treatment facilities and industrial circulating water systems.
4. Light Manufacturing Automation: Core controller for packaging, textile, food processing and other discrete manufacturing production lines.
5. Building & Public Utilities: Automation control for large commercial buildings, logistics warehouses and municipal public facility systems.

Same Series Model Display

1. ABB PM863K01: Mid-range AC 800M processor unit, balancing performance and cost for standard industrial control scenarios with medium I/O capacity.
2. ABB PM865K01: Upgraded AC 800M processor unit, with expanded memory and higher processing performance for medium-large scale distributed control systems.
3. ABB PM867K01: Flagship high-integrity AC 800M processor unit, with SIL3 safety certification for safety-critical industrial control scenarios.

Related Supporting Product Model Display

1. ABB CI854: PROFIBUS DP communication interface module, realizing high-speed fieldbus connection between PM861K01 and distributed field I/O stations.
2. ABB SS822: Redundant power supply module, providing stable redundant 24V DC power input for PM861K01 to eliminate power supply single point of failure.
3. ABB TB850: Dedicated CEX-bus terminator, providing reliable bus signal termination for PM861K01 system.
4. ABB DI810: Digital input module, expanding field digital signal acquisition capacity for control systems.
5. ABB AI810: Analog input module, collecting analog physical quantity signals such as temperature and pressure for .
