CONVERTEAM P111-6053 System Control Board

Description

CONVERTEAM P111-6053 System Control Board

Executive Brief

The CONVERTEAM P111-6053 is a high-performance industrial embedded system control board built around the Rockchip RK3588 processor, designed for industrial automation, edge computing and embedded control scenarios. It features rich peripheral interfaces, strong expandability and industrial-grade stability, and is widely deployed in industrial control, intelligent manufacturing, environmental monitoring and other industrial fields.

P111-6053

Core Technical Specifications

1. Manufacturer: CONVERTEAM
2. Exact Part Number: P111-6053
3. Product Category: Industrial Embedded System Control Board
4. Processor: Rockchip RK3588
5. Onboard Memory: 4/8GB LPDDR4, maximum expandable to 32GB
6. Storage Interfaces: 1SATA 3.0, 1eMMC (max 128GB), 1*TF card slot
7. Display Interfaces: 2HDMI_TX, 1HDMI_RX, 1*dual-channel 24bit LVDS
8. Network Interfaces: 2*LAN, onboard Wi-Fi (Wi-Fi 6 optional), onboard Bluetooth (BT5.0 optional)
9. Serial Ports: 6COM (4RS-232, 2*RS-232/485 adaptive)
10. USB Interfaces: 4USB3.0, 4USB2.0
11. Expansion Slots: 1Mini-PCIe (supports 4G module), 1M.2 (supports 5G module)
12. Other I/O: 12GPIO, 1CAN, 1FAN interface, 1Touch interface, 2*LED indicators
13. High-density Connector: 2100Pin connectors, leading out 1-lane X4 / 4-lane X1 PCIE, 1TYPEC/DP, 2MIPI_TX, 4MIPI_RX, 3I2C, GPIO, 2CAN BUS and other signals
14. Physical Dimensions: 146mm x 115mm
15. Application Fields: Industrial CNC machinery, metallurgy, oil & gas, petrochemical, papermaking & printing, textile, electronic manufacturing, automotive manufacturing, plastic machinery, electric power, water conservancy, environmental protection, municipal engineering, boiler heating, energy and power distribution systems

Key Features & Advantages

• Flagship-level Computing Performance: Powered by Rockchip RK3588 high-performance processor, with up to 32GB expandable LPDDR4 memory, delivering powerful edge computing and data processing capabilities.
• Ultra-rich Peripheral Interfaces: Integrates complete display, network, serial port, USB and industrial I/O resources, no additional expansion boards required for most industrial control scenarios.
• Full 5G/4G Wireless Expansion: Native Mini-PCIe and M.2 slots support 4G and 5G modules, easily realizing industrial wireless communication and edge IoT access.
• Industrial-grade Communication Compatibility: 6 serial ports including 2 adaptive RS-232/485 ports perfectly adapt to various industrial field instrument and sensor access requirements.
• High-density Signal Expansion: 2*100Pin high-performance connectors lead out complete PCIE, video, bus and other signals, supporting flexible secondary development and function expansion.
• Compact Industrial Form Factor: 146mm x 115mm compact size, suitable for installation in space-constrained industrial control cabinets and embedded equipment.

P111-6053

Typical Application Scenarios

1. Industrial CNC Equipment Control: Core embedded control board for CNC machinery and automated production line control systems.
2. Edge Computing Gateways: High-performance industrial edge computing node for industrial IoT data collection, processing and transmission.
3. Intelligent Manufacturing Terminals: Human-machine interaction and control core for intelligent manufacturing workshop operation terminals and industrial HMI devices.
4. Environmental & Water Treatment Monitoring: Dedicated control board for environmental protection, water treatment and municipal engineering online monitoring equipment.
5. Power & Energy Systems: Embedded control unit for power distribution, boiler heating and energy management industrial control equipment.

Related Supporting Product Model Display

1. CONVERTEAM RK3588 Series Industrial Boards: Other RK3588-based industrial control boards with different interface configurations and form factors.
2. Industrial 4G/5G Communication Modules: Compatible 4G and 5G modules that can be installed in the Mini-PCIe and M.2 slots of P111-6053.
3. Industrial HMI Display Screens: Industrial-grade displays that can be connected via HDMI or LVDS interfaces to build complete human-machine interaction systems.
4. Industrial Serial Peripherals: Various industrial sensors, instruments and actuators that can be connected via RS-232/485 serial ports.

Frequently Asked Questions

Q1: What processor does CONVERTEAM P111-6053 use?
A1: It is equipped with the Rockchip RK3588 high-performance processor.

Q2: What is the maximum expandable memory of this control board?
A2: The onboard LPDDR4 memory can be expanded up to 32GB.

Q3: Does P111-6053 support 5G module expansion?
A3: Yes, it has a dedicated M.2 slot that supports 5G module installation.

Q4: How many serial ports does this board have?
A4: It has a total of 6 COM ports, including 4 fixed RS-232 ports and 2 adaptive RS-232/485 ports.

Q5: What are the physical dimensions of ?
A5: The board measures 146mm x 115mm.
