Bently Nevada 3500/05‑01‑01‑00‑00‑01 Full‑Size 19‑inch System Rack for 3500 Machinery Protection System

Description

Bently Nevada 3500/05‑01‑01‑00‑00‑01 Full‑Size 19‑inch System Rack for 3500 Machinery Protection System

Product Details

The 3500/05‑01‑01‑00‑00‑01 is a full‑size 19‑inch panel‑mount system rack belonging to Bently Nevada 3500 TSI machinery protection platform, offering 14 module slots for housing power supplies, rack interface modules, vibration monitoring cards, relay output modules and other functional unitsNEX Instru…. Integrated high‑reliability backplane realizes internal power distribution and high‑speed parallel bus communication among all inserted modules. This rack supports dual redundant power supply installation to improve system availability. Manufactured with heavy‑duty metal enclosure, it complies with CE compliance requirements. It provides stable mechanical support, electrical interconnection and signal transmission foundation for the whole 3500 online monitoring system. It is widely used as original spare‑part and retrofit replacement for turbine‑compressor monitoring cabinets in process industries.

3500/05-01-01-00-00-01

Applications

‑ Power plant steam / gas turbine TSI vibration protection system ‑ Oil & gas centrifugal compressor and expander machinery monitoring ‑ Petrochemical plant rotating equipment safety supervision ‑ Refinery large pump, fan and gearbox condition monitoring ‑ Energy‑chemical reciprocating compressor protection system ‑ Industrial machinery protection cabinet renovation and spare‑part replacement ‑ Critical rotating asset online condition monitoring per API‑670 standard

Related Series Models (6+)

1. 3500/05‑01‑02‑00‑00‑01
2. 3500/05‑02‑04‑00‑00‑01
3. 3500/15‑05‑00‑00 Power Supply Module
4. 3500/20‑01‑01‑02 RIM Rack Interface Module
5. 3500/22‑01‑01‑00 TDI Interface Module
6. 3500/42‑01‑01‑00 Vibration Monitor Module
7. 3500/32‑01‑00‑00 Relay Module
8. 3500/50‑01‑00‑00 Keyphasor Module

Key Features

1. Full‑size 19‑inch standard cabinet structure with 14 configurable slots, supports flexible mixed‑configuration of various 3500 series modules本特利.
2. High‑quality integrated backplane, realizes power distribution and high‑speed internal bus communication for all inserted cards.
3. Supports dual redundant power supply installation, improves system anti‑fault capability for non‑stop monitoring.
4. Panel‑mount installation mode, convenient for cabinet layout and field wiring maintenance.
5. CE‑certified rugged metal mechanical housing, anti‑vibration and anti‑shock for heavy‑industrial site environment.
6. Hot‑swap compatible architecture, allows module replacement without rack power‑off.
7. Perfect compatibility with full‑range Bently Nevada 3500 series monitoring and communication modules.
8. Designed in accordance with API‑670 machinery protection industry specification for critical rotating equipment.

Main Functions

1. Provide mechanical mounting base for 3500 series power supply, interface, monitoring and relay modules.
2. Distribute stable working power to each internal module via backplane circuit.
3. Build high‑speed parallel internal bus to realize data interaction between all inserted functional cards.
4. Support installation of dual power units to achieve power redundancy for high‑availability monitoring system.
5. Realize electrical interconnection and signal routing for the whole machinery protection rack.
6. Adopt panel‑mount mechanical structure to fix the complete TSI rack inside industrial control cabinet.
7. Cooperate with RIM/TDI interface module to complete system configuration upload/download and upper computer communication.
8. Serve as the hardware foundation for rotating machinery vibration, displacement, speed and temperature online protection.
