Bently Nevada 146031-01 (3500/22M) Transient Data Interface (TDI) Module
Product Description
The 146031-01 is the core I/O board for Bently Nevada 3500/22M Transient Data Interface module within the 3500 series machinery monitoring rack. It integrates the functions of rack interface and high-speed waveform data acquisition, capturing both steady-state values and high-resolution transient vibration waveforms from all monitor modules in the 3500 rack. The module transmits captured time-domain waveform, keyphasor and event data over Ethernet to System 1 machinery health management software for post-event spectrum analysis, orbit plotting and fault diagnosis. It supports hot-swap operation without rack shutdown and continuous self-diagnosis for communication and hardware faults, serving as the critical gateway for advanced vibration diagnostics on critical rotating machinery protection systems.
Technical Specifications
- Part Number: 146031-01
- Manufacturer: Bently Nevada (Baker Hughes)
- Series: 3500 Series (3500/22M TDI)
- Device Type: Transient Data Interface I/O Module
- Input Signal Range: -10 VDC ~ +10 VDC
- Power Consumption: 10.5 W
- Ethernet Interface: 10BASE-T /100BASE-TX RJ45
- Sampling: High-speed synchronous sampling for transient waveform capture
- Power Supply: Powered by 3500 rack backplane
- Operating Temperature: -30°C ~ +65°C
- Storage Temperature: -40°C ~ +85°C
- Relative Humidity: 5%~95%, non-condensing
- Mounting: Hot-swappable slot inside 3500 rack
- Weight: Approx. 0.82 kg
- Compliance: API 670, CE, UL
146031-01
Key Features
- High-speed transient waveform acquisition for vibration and keyphasor signals
- Merges rack interface and data communication processor in one compact board
- Hot-swappable design for maintenance without system power interruption
- 10/100Mbps Ethernet for high-volume waveform transfer to System 1 software
- Simultaneously collects steady-state measurements and post-fault transient snapshots
- Continuous hardware and communication self-diagnosis with fault indication
- Synchronized multi-channel sampling for orbit, spectrum and rotor dynamic analysis
- Robust metal enclosure for long-term service in power and petrochemical cabinets
Application Scenarios
- Power plant gas turbine, steam turbine and generator vibration diagnostics
- Petrochemical refinery compressors, pumps and large rotating equipment
- Offshore platform rotating machinery condition monitoring
- Pipeline turbo-compressor fault capture and post-trip analysis
- Pulp & paper large fan and motor transient event recording
- Metallurgy heavy rotating machinery vibration waveform capture
- Combined cycle power plant machinery predictive maintenance
- Critical rotating asset root-cause failure analysis
Matching / Auxiliary Components
- 3500 series rack chassis (3500/05)
- 3500 rack power supply module (3500/15)
- Vibration / proximity monitor modules (3500/40M, 3500/42M)
- Keyphasor module (3500/25)
- 3300XL proximity probes and extension cables
- Industrial shielded Ethernet cables
- Bently System 1 condition monitoring & diagnostic software
- 3500 configuration software
