ABB CPM810 Common Processor Module



Executive Brief

The ABB CPM810 is the core general processor unit in the ABB Bailey turbine control family, serving as the “运算大脑” for AS800 synchronization systems, TP800 turbine protection systems and VP800 valve positioning systems. It is always paired with the dedicated TBU810 terminal base unit, forming the “computing center + signal hub” core combination for precision control of critical power equipment such as thermal power units, gas turbines and steam turbines.

CPM810

Core Technical Specifications

  1. Manufacturer: ABB
  2. Product Category: Common Processor Module (CPM)
  3. Product Family: ABB Bailey Turbine Control Series
  4. Supporting Base Unit: TBU810 dedicated terminal base unit, one-to-one paired with CPM810
  5. Core Functions: Executes closed-loop control algorithms such as PI regulation, processes LVDT position feedback signals, drives servo valves and I/H converters
  6. Communication Interface: Integrated Profibus interface, supports redundant communication and remote diagnosis
  7. Application Scenarios: Widely used in precision control of key power equipment including thermal power, gas turbines and steam turbines
  8. System Compatibility: Perfectly adapts to AS800 synchronization system, TP800 turbine protection system and VP800 valve positioning system



Key Features & Advantages

  • Dedicated Turbine Control Architecture: Purpose-built for ABB Bailey turbine control systems, with highly optimized control logic for turbine operation characteristics.
  • High-precision Control Capability: Executes closed-loop PI regulation algorithms, processes LVDT position feedback in real time, and achieves ultra-high precision positioning control for turbine valves.
  • Redundant Communication Support: Integrated Profibus interface supports redundant communication, effectively eliminating communication single point of failure and improving system operation reliability.
  • Seamless Matching Design: One-to-one paired with TBU810 dedicated terminal base unit, realizing plug-and-play installation and stable signal connection.
  • Wide Industry Adaptability: Suitable for various key power equipment control scenarios such as thermal power, gas turbines and steam turbines, meeting the strict reliability requirements of power generation industries.



Typical Application Scenarios

  1. Thermal Power Unit Turbine Control: Core control processor for large and medium-sized thermal power plant steam turbine regulation systems, realizing precise valve positioning and speed regulation.
  2. Gas Turbine Precision Control: Main control unit for industrial gas turbines in combined cycle power plants, ensuring stable and efficient operation of gas turbine units.
  3. Turbine Protection System: Core operation unit for TP800 turbine protection systems, processing real-time fault signals and executing rapid protection response logic.
  4. Synchronization System Control: Core processing unit for AS800 generator synchronization systems, realizing precise grid connection control for generator sets.
  5. Petrochemical Turbine Drives: Precision control for large industrial turbines driving compressors and pumps in petrochemical production facilities.



Related Supporting Product Model Display

  1. ABB TBU810: Dedicated terminal base unit for CPM810, providing physical installation, electrical connection, signal distribution and power interface for the processor module.
  2. ABB LVDT Position Sensor: Field position feedback sensor, collecting turbine valve position signals and transmitting them to CPM810 for processing.
  3. ABB Servo Valve: Actuator controlled by CPM810, receiving control signals to adjust the opening of turbine valves.
  4. ABB Profibus Redundant Communication Module: Expanding redundant Profibus communication capacity for , improving communication reliability.
  5. ABB Redundant Power Supply Module: Providing stable redundant power input for and TBU810, eliminating power supply single point of failure.



Frequently Asked Questions

Q1: What is the full name of ABB ?
A1: Its full name is Common Processor Module, which is the general processor module in ABB Bailey turbine control family.

Q2: What supporting base unit does need to work with?
A2: It must be used in one-to-one pairing with the dedicated TBU810 terminal base unit, which provides physical installation and signal connection functions.

Q3: What core functions can achieve?
A3: It executes closed-loop control algorithms such as PI regulation, processes LVDT position feedback, and drives servo valves to realize precise positioning of turbine valves.

Q4: What communication interface does integrate?
A4: It is integrated with Profibus interface, which supports redundant communication and remote diagnosis functions.

Q5: Which ABB systems is compatible with?
A5: It perfectly adapts to AS800 synchronization system, TP800 turbine protection system and VP800 valve positioning system.
