ProSoft MVI56-104S IEC 60870-5-104 Server Communication Module for ControlLogix

Description

ProSoft MVI56-104S IEC 60870-5-104 Server Communication Module for ControlLogix

Product Description

The MVI56-104S is an in-chassis communication gateway module manufactured by ProSoft Technology for Rockwell Allen‑Bradley ControlLogix platform. It functions as an IEC 60870-5-104 server, bridging ControlLogix PLC and IEC 104-based SCADA/DCS systems over TCP/IP Ethernet. It exchanges real-time process data via the ControlLogix backplane with the controller and provides IEC 104 telecontrol services for upper-level power SCADA. It supports spontaneous unsolicited data reporting (Report by Exception), time-stamped event records, group interrogation and time synchronization. A 4000-word internal register database is used for bidirectional data exchange between the ControlLogix CPU and IEC 104 client. It is hot-swappable and widely adopted in power, water and petrochemical telecontrol systems as a protocol conversion spare part.

Technical Specifications

• Part Number: MVI56-104S
• Manufacturer: ProSoft Technology
• Series: MVI56 ControlLogix In-chassis Module
• Device Type: IEC 60870-5-104 Server Ethernet Gateway
• Network Interface: 1 × 10/100BASE-TX RJ45 Ethernet port
• Protocol: IEC 60870-5-104 (Server mode only)
• Default TCP Port: 2404
• Internal Data Register: 4000-word shared database
• Event Queue: Up to 99 records per data type
• Timestamp: 24-bit / 56-bit timestamp configurable; SNTP time sync supported
• Backplane Current Draw: 800mA @5.1VDC; 3mA @24VDC
• Power Dissipation: Approx. 4.1W
• Operating Temperature: 0°C ~ +60°C
• Storage Temperature: -40°C ~ +85°C
• Relative Humidity: 5%~95%, non-condensing
• Mounting: Single slot inside ControlLogix chassis
• Hot Swap: Supported
• Weight: Approx. 0.29 kg
• Certifications: CE, UL, Class I Div 2

MVI56-104S

Key Features

1. IEC 60870-5-104 server gateway for ControlLogix PLC to power SCADA telecontrol
2. Supports spontaneous unsolicited message reporting for event-driven real-time data upload
3. 4000-word internal register space for bidirectional data exchange with Logix controller
4. Configurable time-stamped event logging and SNTP network time synchronization
5. Supports group interrogation, clock sync and IP access filtering for client security
6. Hot-swappable for rack maintenance without full system shutdown
7. LED indicators for module status, Ethernet link and communication fault diagnosis
8. Configuration via ProSoft custom software, integrated with Studio5000 / RSLogix5000

Application Scenarios

• Power plant PLC telecontrol and SCADA interface for power grid dispatch
• Substation automation and remote monitoring systems
• Water & wastewater treatment plant remote telemetry control
• Petrochemical refinery and pipeline SCADA telecontrol
• Renewable energy power station monitoring systems
• Industrial power island remote data acquisition and control
• District heating plant telecontrol and alarm reporting
• Energy management system gateway for IEC104 protocol interconnection

Matching / Auxiliary Components

• ControlLogix 1756 chassis and backplane
• ControlLogix CPU (1756-L71 / L72 / L73 etc.)
• 1756 series AI/AO/DI/DO I/O modules
• 1756-PA75 / PB72 rack power supply
• Shielded CAT5e industrial Ethernet cables
• ProSoft module configuration software
• Studio5000 / RSLogix5000 programming software
• IEC104 SCADA master station / dispatching system

MVI56-104S
