Foxboro FBM231 P0926GV Serial Communication Fieldbus Module
Detailed Product Information
The Foxboro FBM231 P0926GV is a high-performance serial communication module in the Foxboro I/A Series® Fieldbus Module (FBM) family, manufactured by Schneider Electric under the Foxboro brand in the United States. It is purpose-built to connect multiple serial communication field devices seamlessly to industrial distributed control systems, delivering reliable, high-speed data transmission for critical industrial processes where real-time monitoring and control are non-negotiable. The module supports full redundancy at the FBM level, with two paired FBM231 units working in tandem to provide bumpless switchover and fault tolerance, drastically improving system availability and eliminating single points of failure. It is certified for use in Class G3 harsh industrial environments, with a rugged industrial-grade housing that can withstand heavy dust, wide temperature fluctuations and moderate electromagnetic interference in typical heavy process plant settings.
P0926GV
Technical Specifications
- Manufacturer: Schneider Electric (Foxboro brand)
- Part Number: FBM231 P0926GV
- Product Type: Field Device System Integrator Serial Communication Fieldbus Module
- Number of Serial I/O Ports: 4 independent serial communication ports
- Supported Protocols: RS-232, RS-422 and RS-485 full serial protocol compatibility
- Maximum Supported Device Capacity: Up to 64 dual-ported field devices (16 devices per communication port)
- Input Voltage Range: 24 VDC (+5%, –10%)
- Maximum Power Consumption: 7 W per module
- Module Dimensions: 102 mm (4 in) height, 45 mm (1.75 in) width, 104 mm (4.11 in) depth
- Module Net Weight: Approximately 284 g (10 oz)
- Mounting Options: Modular baseplate mounting, DIN rail horizontal/vertical mounting, 19-inch rack mounting with dedicated mounting kit
- Maximum Communication Distance: RS-232 up to 15 m, RS-422/RS-485 up to 1200 m
- Operating Environment: Class G3 harsh industrial environment certified
- Condition: Brand new original factory sealed, 10 units in stock
- Warranty: 12 months official manufacturer warranty
- Origin: USA
Compatibility & Installation Pitfalls
Compatibility
- Natively interoperable with Foxboro I/A Series distributed control systems and matched modular baseplate backplanes
- Fully compatible with all standard industrial serial communication field devices, serial printers, modems and protocol converters
- Seamlessly integrates with Foxboro Experion DCS engineering software for full communication configuration, mapping and diagnostic operations
- Supports standard RS-232, RS-422 and RS-485 serial devices from most third-party industrial automation vendors
- Matches with Foxboro dedicated termination assemblies including ring lug (P0926PA) and compression screw (P0926GH) termination units
Installation Pitfalls
- Never install the FBM231 P0926GV in a slot designated for non-serial FBM modules. Mismatched slot configuration will break the serial communication bus path and cause total serial device communication failure.
- Do not connect serial communication cables longer than the maximum rated distance directly to the module ports without signal repeaters. Excessively long cables will cause severe signal attenuation and communication data corruption.
- Avoid routing serial communication cables connected to this module in the same cable tray as high-power variable frequency drive or AC motor power cables. Severe electromagnetic interference will cause intermittent communication dropouts and data transmission errors.
- Never perform hot-swap replacement while critical process control loops relying on serial communication devices are in automatic operation without pre-engaging the redundant FBM231 partner. This action will cause momentary serial communication loss and trigger unplanned process trips.
- Do not deploy P0926GV modules with drastically different hardware revisions in the same redundant FBM pair. Inconsistent hardware versions will cause asynchronous serial data timing and unexpected data mismatch during redundant switchover.
P0926GV
Standard Operating Procedure
- Pre-installation verification: Inspect the P0926GV module for physical damage on circuit boards and communication ports, confirm the modular baseplate 24V DC power output is stable within the acceptable operating range.
- Mechanical mounting: Align the module with the modular baseplate, slide it smoothly into the designated FBM slot, and secure the mounting lugs to ensure full and reliable electrical contact with the backplane.
- Serial wiring termination: Connect all serial field devices to their corresponding designated ports on the , secure all cable connections properly and apply clear permanent labels for each port with its corresponding device tag number.
- Power-on configuration: Access the Foxboro I/A Series DCS engineering workstation, register the new module to the control system, configure serial communication protocol parameters, baud rate, parity and device address mapping.
- Functional validation: Verify all connected serial field devices are fully recognized and communicating normally, confirm data transmission stability meets system requirements, test the redundant FBM pair bumpless switchover function under simulated fault conditions.
- Commissioning handover: Export and save the final serial communication configuration profile to secure backup, complete the installation and commissioning log, and confirm all serial communication links are operating normally before releasing the system to full operational service.
Typical Application Scenarios
- Petrochemical refining operations: Serves as the serial communication hub connecting serial protocol analyzers, gas chromatographs and other analytical instruments to the Foxboro DCS system.
- Oil and gas production facilities: Deploys in onshore and offshore control cabinets, providing reliable long-distance RS-485 communication for remote field serial sensors and flow totalizers.
- Power generation and utilities: Acts as the communication interface connecting serial protocol vibration monitoring systems and auxiliary equipment controllers to the main distributed control system.
- Chemical processing plants: Leverages its full redundancy support to ensure uninterrupted serial data transmission for critical safety-related serial field devices in harsh corrosive industrial environments.
- Industrial manufacturing facilities: Integrates with legacy serial protocol PLCs and barcode scanners, enabling seamless data exchange between old-generation field devices and modern Foxboro DCS platforms.
Recommended Supporting Components
- Foxboro dedicated modular baseplate with matched DIN rail or 19-inch rack mounting accessories
- Foxboro certified ring lug (P0926PA) or compression screw (P0926GH) termination assembly
- Shielded RS-232/RS-422/RS-485 industrial serial communication cables for interference-free data transmission
- Foxboro official I/A Series DCS engineering configuration software and serial communication diagnostic toolkit
- Industrial serial protocol converter and isolated signal repeater for long-distance serial communication extension
Related Part Number Recommendations
- FBM232: Foxboro standard Ethernet communication module, for industrial Ethernet protocol device connection scenarios
- FBM233 P0926GX: Foxboro high-performance redundant Ethernet fieldbus communication module, for high-availability industrial network communication applications
- FBM234: Foxboro enhanced multi-protocol serial communication module, with additional protocol conversion function for more complex heterogeneous serial device networks
- FBM223: Foxboro legacy serial communication module, for old-generation Foxboro DCS system retrofit and direct replacement
- FBM237: Foxboro high-density serial communication module, for industrial systems that require more than 4 serial communication ports
