Bently Nevada 1900/17 Proximitor Monitor
Bently Nevada 1900/17 Proximitor Monitor - Image 2
Bently Nevada 1900/17 Proximitor Monitor - Image 3

Bently Nevada 1900/17 Proximitor Monitor

  1. 1900/15 Vibration Monitor
  2. 1900/25 Vibration Monitor
  3. 1900/27 Vibration Monitor
  4. 1900/55 Fan Monitor
  5. 1900/65A General Purpose Equipment Monitor
  6. 1900/60 Temperature Monitor
  7. 1900/51 Overspeed Monitor
  8. 1900/40 Process Variable Monitor
  9. 1900/05 Display Module
Add To Quote
Category: SKU: Bently 1900/17 Brand:

Description

Bently Nevada 1900/17 Proximitor Monitor



Product Description

The 1900/17 is a compact single-channel Proximitor monitor manufactured by Bently Nevada (Baker Hughes), belonging to the 1900 series standalone machinery protection monitors. It works with Bently proximity transducer systems to measure shaft relative vibration, radial displacement, shaft position and gap value of rotating equipment. This unit converts the high-frequency eddy-current probe signal into usable 4–20mA analog output and configurable relay alarm/trip outputs. With local LED status indicators and easy threshold configuration, it delivers continuous online monitoring and protection for critical rotating machinery. As a DIN-rail mount standalone monitor, it is widely used for smaller rotating assets where a full 3500 rack system is unnecessary.

1900/17

Technical Specifications

  • Part Number: 1900/17
  • Manufacturer: Bently Nevada (Baker Hughes)
  • Device Type: Proximitor Monitor (Eddy Current Probe Interface)
  • Channel: 1 channel for proximity probe input
  • Supported Transducer: 3300 XL series proximity probe system
  • Measurement: Shaft relative vibration, gap / axial position
  • Analog Output: 4–20mA proportional to measured variable
  • Relay Outputs: 2 programmable relays for Alert and Danger trip
  • Power Supply: 24 VDC
  • Mounting: 35 mm DIN rail
  • Operating Temperature: -40°C ~ +70°C
  • Relative Humidity: 5%–95%, non-condensing
  • Approvals: CE, meets API 670 machinery protection standard
  • Enclosure: IP20 for cabinet installation
  • Status Indication: LED indicators for power, alarm, trip, fault



Key Features

  1. Single-channel proximitor monitor for eddy-current proximity probe systems
  2. Measures shaft relative vibration and shaft displacement for rotating machinery
  3. 4–20mA analog output for connection to PLC, DCS and SCADA systems
  4. Dual programmable relay outputs for Alert and Danger protection trips
  5. Built-in probe fault detection (open circuit / short circuit)
  6. DIN rail compact design, simple installation inside control cabinets
  7. Local LED indicators for quick on-site status diagnosis
  8. API 670 compliant for machinery protection applications



Application Scenarios

  • Industrial pumps, fans and blowers shaft vibration monitoring
  • Small & medium compressors radial vibration and position protection
  • Steam turbine auxiliary equipment monitoring
  • Motor and gearbox shaft relative displacement measurement
  • Petrochemical refinery rotating machinery protection
  • Water treatment large pump condition monitoring
  • Cement plant fan and kiln auxiliary machinery
  • Offshore skid-mounted small rotating equipment protection

1900/17

Matching / Auxiliary Components

  • 3300 XL proximity probe (330104 / 330105 series)
  • 3300 XL extension cable
  • 3300 XL proximitor transducer
  • 24VDC industrial power supply
  • Shielded coaxial probe cables
  • DIN rail mounting hardware
  • PLC / DCS analog input modules
  • Bently TK-3 calibration test kit
  • Relay wiring terminals for trip interlock
