ABB CI869K01 (3BSE049110R1) AF100 Advant Fieldbus 100 Communication Interface Module for AC800M / System 800xA

Description

ABB CI869K01 (3BSE049110R1) AF100 Advant Fieldbus 100 Communication Interface Module for AC800M / System 800xA

Product Details

CI869K01, part number 3BSE049110R1, is CEX‑bus expansion communication module for ABB AC 800M controller, belongs to System 800xA DCS platform. Origin: SwitzerlandAlibaba.co…. Lifecycle status: EOL discontinued, OEM new production stopped; market supplies are NOS surplus and fully‑tested refurbished spare‑parts for plant maintenanceABB.

It provides Advant Fieldbus 100 (AF100) twisted‑pair (TWP) interface, enables AC800M to communicate with legacy AC160, AF100 fieldbus devices and connectivity serversabb-drive ….

• Protocol: ABB proprietary AF100
• Baud rate: 1.5 Mbit/sABB
• Bus interface: Twisted‑pair modem, supports cable redundancy and dual‑module redundancy
• Support hot‑swap, compatible with AC800M HI high‑integrity safety controller systemABB
• Powered via CEX‑bus from rack backplane (24VDC)
• Operating temperature: ‑20℃ ~ +55℃, IP20
• Weight: approx 0.73 kg
• Installation: AC800M rack slot via CEX‑bus

Applications

‑ Power plant System 800xA DCS, connect legacy station and AC160 controllers ‑ Petrochemical process control system AC800M and old‑generation Advant system interconnection ‑ fieldbus network redundancy configuration ‑ Connect to AC100 OPC server via CI527A on connectivity server side ‑ Retrofit & spare‑part replacement for existing AC800M racks ‑ Spare inventory for plant DCS maintenance department

CI869k01

Related Series Models (6+)

1. CI869 (base model, same hardware as CI869K01)
2. CI527A ( interface for connectivity server side)
3. CI854A (Profibus‑DP communication module for )
4. CI867A (Modbus‑TCP interface module)
5. PM866K01 ( main CPU)
6. CI810B ( fiber‑optic communication module)
7. CI857K01 (INSUM interface module)

Key Features

1. Dedicated Advant Fieldbus‑100 communication interface for controller under System 800xA platform.
2. Integrated twisted‑pair modem, supports 1.5 Mbit/s bus communication, realize data exchange between and legacy Advant equipment.
3. Support cable redundancy and dual‑module redundancy for high‑availability process control scenariosABB.
4. Hot‑swap capable; can be replaced online without rack power‑off.
5. Compatible with HI high‑integrity safety‑related controller system.
6. Connectivity to AC100 OPC server for legacy system data access.
7. Installed on rack via CEX‑bus, no separate external power supply required.
8. Manufactured in Switzerland; EOL obsolete, only NOS or fully‑tested refurbished spare‑parts available.

CI869k01

Main Functions

1. Act as fieldbus gateway for controller, realize data interaction with legacy AC160 and field‑stationsabb-drive ….
2. Support single‑cable redundant and dual‑module redundant configuration, improve communication reliability.
3. Realize inter‑controller data exchange between new and old Advant control system.
4. Cooperate with CI527A on connectivity server side to connect AC100 OPC server, access legacy system data.
5. Monitor bus status, report communication fault diagnostics to System 800xA operator station.
6. Hot‑swap function supports online maintenance, reduces plant downtime risk.
7. Work together with PM86x series CPU and other CEX‑bus modules to build complete DCS hardware architecture.
8. Serve as fieldbus communication interface unit inside ABB control rack.
