ABB ACU-01B (3HNA024871-001) Air Control Unit for IRC5P Painting Robot

Description

ABB ACU-01B (3HNA024871-001) Air Control Unit for IRC5P Painting Robot

Product Description

The ACU-01B, order code 3HNA024871-001, is an Air Control Unit dedicated to ABB IRC5P paint robots (IRB5500 painting robot series). It replaces the older PPRU/MAC unit, precisely regulating air pressure, paint flow and atomizing air for the spray gun. The unit integrates precision pneumatic proportional valves, pressure sensors, control electronics and communication interface. It receives setpoints from the IRC5 robot controller, executes closed-loop air pressure control, and feeds back measured pressure, flow and fault status back to the robot system. It supports pre-calibration and on-site fine tuning, ensures consistent coating quality and stable spraying parameters. It is installed directly on the robot arm and is a critical spare part for automotive paint shop robot systems.

ACU-01B 3HNA024871-001

Technical Specifications

• Part Number: ACU-01B, 3HNA024871-001
• Manufacturer: ABB Robotics
• Series: IRC5P Paint Robot System
• Device Type: Air Control Unit (ACU) for spray painting
• Communication: Ethernet, digital I/O interface to IRC5 controller
• Medium: Compressed dry air, paint fluid
• Pressure Control: Precision closed-loop proportional air regulation
• Software Requirement: RobotWare RW5.07.02 or higher
• Dimensions: 210 × 140 × 160 mm
• Weight: 3.66 kg
• Operating Temperature: 5°C ~ +50°C
• Storage Temperature: -20°C ~ +70°C
• Relative Humidity: 5%~95%, non-condensing
• Mounting: Mounted on robot arm (IRB5500)
• Protection: Enclosure designed for paint booth environment
• Certifications: CE, UL

Key Features

1. Integrated air & paint flow closed-loop control for ABB IRC5P painting robots
2. Direct replacement for legacy PPRU / MAC pneumatic control assemblies
3. High-precision proportional valve control to stabilize atomizing and shaping air
4. Built-in pressure sensing, real-time feedback and automatic parameter monitoring
5. Pre-calibrated from factory, supports quick on-site fine adjustment
6. Ethernet and digital I/O interface for data exchange with IRC5 robot controller
7. Compact integrated unit, arm-mounted for short pneumatic piping
8. Comprehensive fault diagnostics for pressure deviation, valve and sensor failure

Application Scenarios

• Automotive body paint shop IRB5500 spray robot systems
• Automotive component painting and coating lines
• General industrial product automated spraying production
• Metal surface coating and paint application automation
• Plastic part painting in automotive and appliance factories
• Continuous painting lines with high repeatability requirements
• Refurbishment and spare replacement for existing IRC5P paint robots
• Robotic coating process quality stabilization and parameter control

ACU-01B 3HNA024871-001

Matching / Auxiliary Components

• ABB IRC5P robot controller and main computer unit
• IRB5500 painting robot mechanical arm
• Robot spray gun and nozzle assembly
• Clean dry compressed air supply unit and air filter regulator
• Robot cable harness and pneumatic tubing
• RobotWare software for ACU parameter configuration
• Pressure calibration tool for periodic verification
• Mounting brackets and sealing spare kits
